Construction of a 4×12×1.4 m Concrete Swimming Pool with Salt System (Skimmer System) ⭐ Special All-Inclusive Price: 1,390,000 THB ⭐

Construction of a 4×12×1.4 m Concrete Swimming Pool with Salt System (Skimmer System) ⭐ Special All-Inclusive Price: 1,390,000 THB ⭐

(0)

SKU : POOL-SK-4X12X1-4

A 4×12×1.4 meter concrete swimming pool is one of the most popular choices for premium homes, resorts, and residential projects that require a larger pool ideal for lap swimming, relaxation, and family use. This model offers the perfect long-length swimming experience similar to a lap pool, while maintaining a clean and modern aesthetic. Combined with a saltwater system, the pool is easy to maintain, safe for the skin, and cost-effective in the long run. Win Win Engineering Supply constructs concrete swimming pools using building-grade structural standards. Each pool begins with I22 micro-piles, 10 piles at a depth of 16–21 meters, to support the heavy load of the concrete structure—over 60–70 tons—effectively preventing long-term settlement. The structure is then reinforced with steel bars throughout the floor and walls, poured with waterproof concrete, and finished with premium 10×10 cm natural stone tiles, known for durability and luxury appearance. The pool is completed with natural stone coping for beauty and safety. The pool system is designed as a complete package, equipped with high-quality components including a Laswim 1.5HP circulation pump, 700 mm top-mount sand filter, and the EC30 salt chlorinator, providing crystal-clear and skin-friendly saltwater. LED underwater lighting enhances nighttime ambience, while full cleaning equipment and a built-in spa seat system with jets and air valves elevate the overall pool experience. Our experienced installation team manages everything from piping, electrical work, equipment installation, water balancing, and system testing, to full on-site training to ensure smooth operation. Every project includes a 5-year structural warranty, 2-year system installation warranty, and 1-year equipment warranty, offering complete peace of mind. This information represents a condensed BOQ to help customers understand the general scope of work. For the full detailed BOQ or further consultation, please contact our Project Sales Team during business hours.

฿1,390,000

There is an installment plan with a 0% interest rate (you can check the monthly installment calculation on the payment page).

Promotion

Minimum spent ฿5,000 discount 5%

Minimum spent ฿20,000 discount 6%

Minimum spent ฿40,000 discount 7%

Minimum spent ฿50,000 discount 8%

Quantity

Request a Quote

Categories : wimming Pool Construction Pricing , สระคอนกรีตแบบ Skimmer

Product description

Construction of a 4×12×1.4 m Concrete Swimming Pool with Salt System (Skimmer System)
⭐ Special All-Inclusive Price: 1,390,000 THB ⭐

(Down from the regular price of 1,394,211.61 THB special discount for customers)
This price is a starting price, adjustable depending on actual site conditions, and negotiable.

High-Standard Structural Works with I22 Micro-Piles
I22 micro-pile foundations: 10 piles, depth 16-21 meters
Excavation, backfilling, leveling, and sand bedding
Full reinforced-concrete structure for pool floor and walls
Waterproof concrete for the pool floor: 17 cubic meters
Waterproof concrete for pool walls: 9 cubic meters
DB12 reinforcing steel: over 300 bars
Cement plastering and full waterproofing treatment
Natural stone tiles (10×10 cm) installed throughout:

Floor area: approx. 51 m²
Wall area: approx. 47 m²
Natural stone coping 30×30 cm: 36 meters
Built-in concrete steps + integrated spa seating

️ Pool System & Equipment (Salt System + Spa Set)
Filtration pump Laswim SWPB150, 1.5 HP
Sand filter WL-IDG700 Top-Mount 28" (700 mm)
Salt chlorinator EC30, 30 g/hr output
Complete control panel with timer
Spa pump system with jets, air valves, and air switch
Skimmer, main drain, inlets, eyeballs, and stand vacuum
Underwater LED lights 12V/DC: 6 units
Stainless-steel junction boxes
Complete pool cleaning kit
Startup chemicals + 13 bags of pool salt

Full Installation & System Setup
Complete PVC 13.5 piping system
Electrical wiring + control panel installation
Installation of pump, filter, salt system, and spa system
Water balancing and preparation for use
System testing (Test Run + Commissioning)
On-site training for customer operation

Special All-Inclusive Price
⭐ 1,390,000 THB (NET) ⭐
Starting price adjustable based on actual site conditions
Negotiable depending on project scope

Warranty

5-year structural warranty
2-year system & installation warranty
1-year equipment warranty
3 free service checkups during the first year

Important Notes

This is a condensed BOQ designed to help customers understand the general scope of work.
For the full detailed BOQ, please contact our Project Sales Team.
Landscaping around the pool is not included.
External water supply and drainage systems outside the pump room are not included.
Existing pump room is used as-is, or adjusted based on actual conditions.
